Wonder Arch Liner 610×355 Canopy-type multi-bay shelter — Wonder Arch Liner 400×200Wonder Arch Liner 400×200Illustration
Looking for dedicated Wonder Arch product information? Visit hasshelter.com →

Scope of Supply Options A / B / C

We offer three supply options to match the project stage and procurement route. The same option structure applies to both the Wonder Arch Liner 610×355 and the Wonder Arch Liner 400×200.

OPTION A
Supply

Materials and liner drawings

  • Liner panels and accessories
  • Liner fabrication and assembly drawings (with material take-off)
  • Mill test certificates
  • Export packing and factory inspection
OPTION B
Supply + Engineering

Construction engineering

  • Everything in Option A
  • Assembly instructions (English and local language)
  • Construction-stage liner calculations, reviewed and sealed by a Korean Professional Engineer
  • Temporary support system calculations and concept drawings
  • Erection Plan
  • Site technical support at the first shelter start-up, plus remote support throughout the project
OPTION C
Integrated Engineering Support

Design assist and verification

  • Everything in Option B
  • Design Assist to the Engineer of Record (EOR)
  • Design review and verification
  • LS-DYNA spall liner simulation
  • Certification support
  • Blast door technical package (partner: SH Door Tech)

C-Full (separate option): on request, complete detailed shelter design with our network of Korean design firms.

Construction Engineering (Option B)

Wonder Arch Liner 610×355 assembly - construction engineering
Liner assembly — assembly instructions and site supportIllustration
Wonder Arch Liner 610×355 arch erection with temporary support
Arch erection and temporary support systemIllustration

Responsibilities

Preparation and sealing of the design documents, and responsibility for permits and approvals, rest with the Engineer of Record (EOR) appointed by the Employer or the Contractor. Rexsteel co.,ltd provides the liner drawings and technical support.

The detailed Scope of Supply document for each option is available on request.Request document
